Description
Applications
- Home automation
- Telemetry
Main features
- provided bracket for fixed installation
- No ground plane required
- RoHS compliant
- Good efficency
- Omnidirectional pattern
Main specifications LTE standard
- Parameter/Frequency Band 690-960 MHz 1710-2600 MHz
- Peak Gain (dBi) 1,5 3
- VSWR <1,8 <2
- (Ohm) 50 50
- Polarization Linear Linear
Dimensions 61×150 mm
Connector type Sma
Cable type/length 5mm diameter 10 mt
Temperature range -25/+80C°
